DELETE method found via OPTIONS banner on Opensearch Port 9200

Security
1

Versions (relevant - OpenSearch/Dashboard/Server OS/Browser): Opensearch 2.19.2

Describe the issue: We have VA Scan Vulnerability on opensearch 9200 port that states - “DELETE method found via OPTIONS banner” http-delete-method-enabled

We have to fix this VA Scan issue on 9200 and need possible steps please ? and what i have to add in opensearch.yml and this issue coming om 9200 port not apache or nginc port 443.

opensearch.yml - My Configuration;

cluster.name: opensearch-cluster
node.name: hostname
node.roles: \[master, data\]
action.auto_create_index: “.watches,.triggered_watches,.watcher-history-\*”
network.host: hostname
network.bind_host: hostname
network.publish_host: hostname
http.port: 9200
transport.port: 9300

discovery.seed_hosts:

* hostname1:9300
* hostname2:9300
* hostname3:9300

cluster.initial_cluster_manager_nodes:

* hostname1
* hostname2
* hostname3

######## Start OpenSearch Security Demo Configuration ########

plugins.security.ssl.transport.enabled: true
plugins.security.ssl.transport.pemcert_filepath: “/app/BBT/ssl//server.crt”
plugins.security.ssl.transport.pemkey_filepath: “/app/BBT/ssl/server_privatedecrypt.key”
plugins.security.ssl.transport.pemtrustedcas_filepath: “/app/BBT/ssl/rootCA.pem”
plugins.security.ssl.transport.enabled_protocols:

* TLSv1.3
* TLSv1.2

plugins.security.ssl.http.enabled_ciphers:

* “TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256”
* “TLS_ECDHE_ECDSA_WITH_CHACHA20_POLY1305_SHA256”
* “TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256”
* “TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256”
* “TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384”
* “TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384”

plugins.security.ssl.transport.enforce_hostname_verification: false
plugins.security.ssl.http.enabled: true
plugins.security.ssl.http.pemcert_filepath: “/app/BBT/ssl/server.crt”
plugins.security.ssl.http.pemkey_filepath: “/app/BBT/ssl/server_privatedecrypt.key”
plugins.security.ssl.http.pemtrustedcas_filepath: “/app/BBT/ssl/rootCA.pem”
plugins.security.ssl.http.enabled_protocols:

* TLSv1.3
* TLSv1.2

plugins.security.ssl.transport.enabled_ciphers:

* “TLS_ECDHE_ECDSA_WITH_AES_128_GCM_SHA256”
* “TLS_ECDHE_ECDSA_WITH_CHACHA20_POLY1305_SHA256”
* “TLS_ECDHE_RSA_WITH_AES_128_GCM_SHA256”
* “TLS_ECDHE_RSA_WITH_CHACHA20_POLY1305_SHA256”
* “TLS_ECDHE_ECDSA_WITH_AES_256_GCM_SHA384”
* “TLS_ECDHE_RSA_WITH_AES_256_GCM_SHA384”

plugins.security.nodes_dn:

* "CN=\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*
  plugins.security.allow_unsafe_democertificates: true
  plugins.security.allow_default_init_securityindex: true
  plugins.security.authcz.admin_dn: \[‘CN=\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*’\]
  plugins.security.audit.type: internal_opensearch
  plugins.security.enable_snapshot_restore_privilege: true
  plugins.security.check_snapshot_restore_write_privileges: true
  plugins.security.restapi.roles_enabled: \[“all_access”\]
  plugins.security.restapi.endpoints_disabled:
  "*": \[“DELETE”\]
  plugins.security.system_indices.enabled: true
  plugins.security.system_indices.indices: \[.opensearch-security, .plugins-ml-agent, .plugins-ml-config, .plugins-ml-connector,
  .plugins-ml-controller, .plugins-ml-model-group, .plugins-ml-model, .plugins-ml-task,
  .plugins-ml-conversation-meta, .plugins-ml-conversation-interactions, .plugins-ml-memory-meta,
  .plugins-ml-memory-message, .plugins-ml-stop-words, .opendistro-alerting-config,
  .opendistro-alerting-alert*, .opendistro-anomaly-results\*, .opendistro-anomaly-detector\*,
  .opendistro-anomaly-checkpoints, .opendistro-anomaly-detection-state, .opendistro-reports-*,
  .opensearch-notifications-*, .opensearch-notebooks, .opensearch-observability, .ql-datasources,
  .opendistro-asynchronous-search-response\*, .replication-metadata-store, .opensearch-knn-models,
  .geospatial-ip2geo-data\*, .plugins-flow-framework-config, .plugins-flow-framework-templates,
  .plugins-flow-framework-state\]
  node.max_local_storage_nodes: 3

Configuration:

roles.yml:

\_meta:
type: “roles”
config_version: 2

readonly_role:
cluster_permissions:
- cluster:monitor/\*
index_permissions:
- index_patterns:
- ‘\*’
allowed_actions:
- read
- write
# No delete permission

roles_mapping.yml

---

# In this file users, backendroles and hosts can be mapped to Security roles.

# Permissions for OpenSearch roles are configured in roles.yml

\_meta:
type: “rolesmapping”
config_version: 2

all_access:
reserved: false
backend_roles:

* “admin”
  description: “Maps admin to all_access”

readonly_role:
users:
- “readonly”

internal_users.yml

---

# This is the internal user database

# The hash value is a bcrypt hash and can be generated with plugin/tools/hash.sh

\_meta:
type: “internalusers”
config_version: 2

# Define your internal users here

## Demo users

admin:
hash: “$2y$12$eeszaFEDaVTCEPjGJT9Q3ebUX1SEg2IjB/JLgs0shGsFW6IUjSHPy”
reserved: true
backend_roles:

* “admin”
  description: “Admin user”

bitbucket:
hash: “$2y$12$eeszaFEDaVTCEPjGJT9Q3ebUX1SEg2IjB/JLgs0shGsFW6IUjSHPy”
backend_roles:

* “admin”
  description: “Admin user”

readonly:
hash: “$2y$12$eeszaFEDaVTCEPjGJT9Q3ebUX1SEg2IjB/JLgs0shGsFW6IUjSHPy”  # hashed password
reserved: false
backend_roles: [ ]
description: “Read-only user”

Relevant Logs or Screenshots:

image1896×979 167 KB

2

@vian

This is a scanner banner finding, not a vuln: OpenSearch legitimately supports DELETE, access is enforced via TLS, auth and RBAC.

I can see you tried to disabled DELETE using: plugins.security.restapi.endpoints_disabled but this only affects the Security plugin APIs, not core endpoints, therefore it will not change what OPTIONS advertises.

If you are looking to harden the cluster I would recommend to:

  1. Not expose 9200 publicly.
  2. Enable TLS/auth.
  3. Set action.destructive_requires_name: true which will prevent accidental deletions.

If, however, you have to hide this verb for audit reasons or others, you will need to do it in a reverse proxy/WAF, not via opensearch.yml

Hope this helps

1 Like
3

Hi Anothny , what is the memaing of 9200 not to expose public? How to do that as opensearch we are not intent to relase any internet facing and how to handle this situation and explain to my organisation as this not vulnerable? And i already enabled the SSL/ TLS in my configuration. Attached the config details abive already.If we have any document link that explains this can you help to share? So that i can talk to VA scan team to explain override this case.

4

@vinay It just means HTTP port should not be reachable from the internet, allow only internal subnets or a reverse proxy/WAF via firewall/security-group rules, while keeping TLS and auth enabled.

There is no document that I’m aware of that will explain how delete operation is not a vulnerability. I think looking at this from a more holistic view is a better approach when it comes to explaining this to the VA scan team.

1 Like
